Socomec
Socomec Digiware I-30 1x 3PH or 3x 1PH Energy Meter
- Item No.:
- 48290110
- Product Range:
- Digiware I
Download product datasheet
Popular Accessories
Electrical
- Pole type
- Three conductor/four conductor
- Voltmeter
- No
- Ampere meter
- Yes
- Pulse counter
- No
- Frequency meter
- No
- Effective power measurement device
- Yes
- Accuracy class active energy according to IEC 62053-22
- Other
- Accuracy class reactive energy according to IEC 62053-23
- Other
- Voltage type of supply voltage
- DC
Construction
- Model
- Measurement transformer
- Number of analogue inputs
- 0
- Number of analogue outputs
- 0
- Number of digital inputs
- 0
- Number of digital outputs
- 0
- Mounting method
- DIN rail
- Degree of protection (IP), front side
- IP20
Communication
- Supporting protocol for other bus systems
- No
- Supporting protocol for Modbus
- Yes
- Supporting protocol for BACnet
- No
- Web server with HTTPS transfer protocol
- No
- Supporting protocol for IEC 61850 Ethernet
- No
- Supporting protocol for OPC UA PubSub
- No
- Supporting protocol for PROFIBUS
- No
- Supporting protocol for PROFINET IO
- No
- With firmware signature
- Yes
Mechanical
- Display
- None
- Remote display
- No
- Connection system
- Screwed terminal
- With rotational speed meter
- No
Dimensions
- Depth
- 65 mm
- Width
- 18 mm
- Height
- 90 mm
Environment
- Operating temperature
- -10...70
- Storage temperature
- -25...70 °C
