Product image is indicative only and provided as a guide.
Socomec
Socomec Remote Fuse Switch RSF BS 4P 400A 230V External Handle
- Item No.:
- RSFDN4004P
- Product Range:
- Fuse Switch
Download product datasheet
Mechanical
- Suitable for fuses
- NH2
- Mechanical life (service cycles)
- 8000 cycles
Electrical
- Rated current
- 400 A
- Max. rated operation voltage Ue AC
- 690 V
- Max. rated operation voltage Ue DC
- 440 V
- Rated permanent current at AC-21, 400 V
- 400 A
- Rated permanent current at AC-23, 400 V
- 400 A
- Rated operation current Ie at DC-21, 220 V
- 315 A
- Rated operation current Ie at DC-21, 440 V
- 315 A
- Rated operation current Ie at DC-22, 220 V
- 315 A
- Rated operation current Ie at DC-22, 440 V
- 315 A
Construction
- Degree of protection (IP), front side
- IP30
Dimensions
- Height
- 238 mm
- Width
- 345 mm
- Depth
- 221 mm
