Product image is indicative only and provided as a guide.
NHP MOD6
NHP MOD6 Miniature Circuit Breaker 6kA 3Pole 25A C Curve
- Item No.:
- MOD6325
- Product Range:
- MOD6 MCB
Download product datasheet
Electrical
- Rated current
- 25 A
- Number of poles (total)
- 3
- Trip curve
- C
- Rated voltage
- 415 V
- Frequency
- 50-60 Hz
- Voltage type
- AC/DC
- Service voltage Ub, AC
- 12 V
- Rated short-circuit breaking capacity Icn according to AS/NZS 60898 at 230 VAC
- 6 kA
- Rated short-circuit breaking capacity Icn according to AS/NZS 60898 at 400 VAC
- 6 kA
Environment
- Pollution degree
- 3
- Rated surrounding temperature without derating
- 30 °C
- Rated temperature
- -25...55 °C
Dimensions
- Height
- 86 mm
- Width
- 54 mm
- Depth
- 76 mm
- Width in number of modular spacings
- 3
- Weight
- 0.36 kg
Mechanical
- Connectable conductor cross section solid-core
- 1-25 mm²
- Connectable conductor cross section multi-wired
- 1-25 mm²
Construction
- Number of protected poles
- 3
- IP rating
- IP40
