Socomec
Socomec ISO Enclosed Isolator, IP 65 Plastic Grey, Handle - Blue, 3P 250A
Item No. ISO3250PGS
Product Range: ISO
Component Type (ETIM Class)
Switch disconnector
Electrical
Rated permanent current Iu250 A
Number of poles3
Frequency50/60 Hz
Rated short-time withstand current lcw17 kA
Rated insulation voltage Ui800 V
Rated impulse withstand voltage Uimp8 kV
Number of auxiliary contacts as normally closed contact0
Number of auxiliary contacts as normally open contact0
Construction
Colour control elementOther
Degree of protection (IP), front sideIP65
Degree of protection (NEMA)4X
Version as reversing switchNo
Mechanical
Padlock lockingYes
Dimensions
Height540 mm
Width360 mm
Depth176 mm
Weight2 kg
Connectable conductor cross section95-150 mm²
