CUBIC

CUBIC CuFlex Flexible Copper Busbar 25mm2 Length 352mm Black and Dark Grey

Item No. FB25352
Product Range: CuFlex
Component Type (ETIM Class)
Busbar
Electrical
Rated current In125 A
Rated current x1 busbar to busbar deltaT 30K-65K145-215 A
Rated current x1 busbar to component deltaT 40K-55K91-107 A
Rated current x1 component to component deltaT 40K-55K91-107 A
Nominal voltage1000 V
Rated short-time withstand current lcc24 A
Rated insulation voltage Ui1000 V
Construction
FlexibleYes
Colour housingGrey/black
Fire resistant propertiesAccording to UL94 V0
Dimensions
Length352 mm
Width20 mm
Height1.5 mm
Wire/conductor size25 mm
Environment
Max. operating temperature105 °C
