Product image is indicative only and provided as a guide.
Carlo Gavazzi
Carlo Gavazzi Timer Relay Multi Function 24V DC and 24 and 240V AC Supply 1CO 0.1 Sec-100Hr
- Item No.:
- DMB01CM24
- Product Range:
- Timer Relays
Download product datasheet
Electrical
- Voltage type for actuating
- AC/DC
- Rated control supply voltage Us at DC
- 24 V
- Rated control supply voltage Us at AC 60HZ
- 20.4-264 V
- Rated control supply voltage Us at AC 50HZ
- 24-240 V
- Number of outputs, delayed, change-over contact
- 1
- Rated operation current Ie at DC-12, 24 V
- 0.2 A
- Rated operation current Ie at DC-13, 24 V
- 2.5 A
- Rated operation current Ie at AC-15, 250 V
- 2.5 A
- Type of electric connection
- Screw connection
Mechanical
- Suitable for DIN rail (top hat rail) mounting
- Yes
- Mechanical lifetime (control contacts)
- 30000000 c (contacts)
- Max. shock acceleration
- 50 g
- Max. vibration acceleration
- 4 m/s²
- Max. vibration frequency, operational
- 100 Hz
Dimensions
- Height
- 80 mm
- Depth
- 109 mm
- Width
- 22.5 mm
Environment
- Operating temperature
- -25...45 °C
