Product image is indicative only and provided as a guide.
Cirprotec
Cirprotec Final Diverters SPD Comm Fine Protect 6V
- Item No.:
- CPTDIN6V2C
- Product Range:
- Final Diverter
Download product datasheet
Electrical
- Nominal voltage AC
- 6 V
- Max. continuous voltage AC
- 7 V
- Nominal discharge surge current (8/20)
- 5 kA
- Max. discharge surge current (8/20)
- 10 kA
- Lightning impulse current (10/350 µs)
- 10 kA
- Voltage protection level core/earth
- 10 V
- Frequency
- 1000000 MHz
- Number of protected wires
- Other
Construction
- Mounting method
- DIN rail (top hat rail) 35 mm
- IP rating
- IP20
Dimensions
- Max. conductor cross section
- 2.5 mm²
- Height
- 90 mm
- Width
- 17.5 mm
- Depth
- 70 mm
- Weight
- 0.06 kg
