Product image is indicative only and provided as a guide.
Allen-Bradley
Allen-Bradley 1606 Power Supply Compact 1Phase 100 to 240V AC to Plus Minus 12 to 15V DC 36W 2.8A
- Item No.:
- 1606XLP36C
- Product Range:
- 1606
Download product datasheet
Electrical
- Voltage type of supply voltage
- AC/DC
- Rated supply voltage at AC 50 Hz
- 100-240 V
- Rated supply voltage at DC
- 85-375 V
- Frequency
- 50-60 Hz
- Nominal current (In)
- 0.4 A
- Max. starting current
- 35 A
- 1st secondary output voltage
- -15...15 V
- Max. output current 1
- 2.5 A
- Nominal value output current 1
- 2.8 A
Construction
- Rail mounting possible
- Yes
- Wall mounting possible
- Yes
- IP rating
- IP20
- Direct mounting possible
- No
- Degree of protection (NEMA)
- Other
Dimensions
- Width
- 45 mm
- Height
- 75 mm
- Depth
- 91 mm
- Weight
- 0.24 kg
Environment
- Operating temperature
- -10...70 °C
- Stabilized
- Yes
