Allen-Bradley
Allen-Bradley 100SC Safety Contactor 5.5kW 4Pole 24VAC Coil 4NC Contact Auxiliary
Item No. 100SC12K404BC
Product Range: 100SC
Component Type (ETIM Class)
Power contactor, AC switching
Electrical
Number of normally open contacts as main contact4
Number of normally closed contacts as main contact0
Rated operation current Ie at AC-3, 400 V12 A
Rated operation power at AC-3, 400 V5.5 kW
Rated operation current Ie at AC-1, 400 V32 A
Max. rated operation voltage Ue AC690 V
Voltage type for actuatingAC
Control supply voltage Us at AC 50HZ24 V
Number of auxiliary contacts as normally open contact0
Construction
Degree of protection (IP)IP20
Mounting methodDIN-rail/screw
Dimensions
Height81 mm
Width45 mm
Depth119.5 mm
Weight0.45 kg
