Ensure efficiency and provide reliable personnel protection with NHP

NHP’s MOD6 M6RCBS 1P RCBO is available with a switched neutral.

This 6kA rated RCBO with a switched neutral retains the same footprint as a regular MCB and at just 18mm wide, is suitable for either a standard 18mm buscomb (typically found in loadcentres) or 3P busbar chassis (typically found in panelboards).

One of the advantages of the MOD6 M6RCBS is the ability to link the main-switch isolator, regular DIN circuit breakers and RCBOs in a loadcenter, all with either pin or fork style busbar comb. This not only saves time during installation, but also during equipment upgrades as the MCBs can simply be replaced with RCBOs, heavily reducing downtime. This quick and seamless process ensures no more linking devices with messy cables.

Offering unmatched reliability and assurance, the entire MOD6 RCBO product range is also backed by NHP’s national service and support promise!

The MOD6 Compact RCBO with switched neutral, features:

  • Suitable for loadcentres or panelboards
  • Single screw line connection (active)
  • Pigtail line connection (Neutral)
  • 2 screw connection load side
  • 6kA rated breaking capacity
  • C curve only
  • AC or A type RCD
  • 30mA trip sensitivity (option 10mA)
  • Current ratings 6A to 32A

The M6RCBS series is one range providing solutions that are available to a wider range of applications. What more could you need from an RCBO? Try it out for yourself and experience the MOD6 difference today!
